Electrical Prefabrication Services
Powered by HC
Improve Speed and Efficiency on the Job Site.
Most contractors do not associate manufacturing with the electrical industry like we do. Offering more than 100,000 square feet of prefabrication space, Hilscher-Clarke Manufacturing strives to push the envelope of what is capable in the prefabrication market. Our electrical prefabrication capabilities allow us to move labor hours offsite into our prefabrication facility, creating a more efficient, safer process. Our mission is to provide a service to the field that will not only help complete the project but also provide efficiency to the work day while allowing concentration on more important aspects of the project.
According to Electrical Contractor magazine, "Prefabricated electrical components are newer, more progressive and efficient, and more often comply with green-building certification programs." That allows Hilscher-Clarke to manage a project’s systems more creatively to employ innovation when creating, shipping, and installing entire assemblies. The BIM Community points to benefits including shorter lead times, greater efficiency, reduced costs, and increased job-site safety.
If you can dream it, we can do it.
Electrical Prefabrication Capabilities:
- GRC nipples up to 6" trade size
- EMT nipples (with or without drive on bushings)
- EMT stub 90s any size
- PVC stub 90s for underground
- EMT/GRC offsets up to 5" trade size
- EMT/GRC 90s up to 4" trade size
- EMT/GRC 90s with kick-up to 4" trade size
- EMT/GRC 4 bend saddles up to 4" trade size
- Plywood cut to any size and painted
- Steel plates cut to any size and painted
- Steel brackets of any size and shape welded and painted
- Unistruts cut to any size 7/8", 1 5/8", back to back.
- Unistrut racks with our without beam clamps, 1/4" or 3/8" allthread
- MC whips for in-wall applications
- MC whips for lighting (normal or luminary type)
- Sealtite or Flex whips with wiring pre-installed
- Underground layouts with Trimble Machine
- In-wall assemblies with or without receptacles pre-installed
- Temporary panel stands with disconnect and receptacles
- Pole-mounted temporary services
- RS covers with devices pre-wired (no one likes to do these in the field, do they?)
- Numbered or lettered wire sleeves for panel hookup
- Pre-wired light fixtures with hangers attached, ready to go
- Fabricated equipment racks color matched to gear, pre-wired, ready to set
- Trench cards
BEGIN AT THE BEGINNING.
Expertise and experience bring you value, but nothing matters more to us than personal and professional values. At our core, Hilscher-Clarke lives to do “FIRST THINGS FIRST”:
Whatever your project and however we work together, you will experience core values that define who we are and how we conduct ourselves — today and every day.
